Product Parameters
Material system | LiFePO4 |
Nominal voltage | 60V |
Nominal capacity | 40/48Ah |
Number of cells in series and parallel | 20S4P |
Battery weight | 21KG/24KG |
Battery size | 366*183*230mm |
Constant current value of charger | 5-10A |
Charging cut-off voltage | 73VDC |
Discharge cut-off voltage | 50VDC |
Maximum continuous discharge current | 48A |
temperature | Working temperature: - 20 ~ 45 ℃, charging temperature: - 10 ~ 45 ℃, storage temperature: 0 ~ 45 ℃ |
Cycle life | 1200 cycles, capacity greater than 70% |
Battery management system | Intelligent BMS one line communication / 485 |
housing | sheet metal, V0 grade fireproof, IP65 grade waterproof |
